Fully automated quartz crystal microbalance system
Pro from QSensePRO is the high-end QCM-D surface analysis equipment. It is an intuitive instrument and software platform that senses mass change, layer thickness, binding and molecular orientation at the nano-scale. It´s 8-sensor module allows high throughput and makes reproducibility easy. High precision flow-control is ensured by using syringe pumps that work separately and allows four channels to be used independently.
Programing automated mixing including concentration gradients of samples ensures high reproducibility.
Temperatures can be set between 4 and 70 °C enabling stable temperature control. Pre-cooling or heating of sample racks is possible.
- Fully automated system with 8 sensor capability
- 30 μl sample needed per sensor
- Flexible choice of surfaces
- Independent channels and automated mixing
- Temperature can be set between 4 to 70 °C enabling stable temperature control
Applications
Measuring molecular interaction
QCM-D can detect and quantify during the binding of small molecules for example the antigene antibody interaction as well as conformational changes in proteins.
Thickness measurements of adhesion layers on surfaces
Molecules such as prolymers bind to surfaces. With QCM-D a quantification of the thickness of such layers can be made.
Desorption measurement
Cleaning properties of detergents can be measured in real time.
Polymer multilayer
Lipid bilayer
Swelling kinetics
Downloads
