NIR compact camera
FX17 from SPECIMFX17 is a hyperspectral camera for the spectral range 900 nm to 1700 nm. It uses an InGaAs detector with a high spatial resolution of 640 pixels. FX17 is equipped with an F/1.7 Specim lens. It boasts high light throughput and features a high signal-to-noise ratio of 1000:1 and short integration times. Thus, there is basically no need for external illumination. FX17 has high frame rates of 670 fps full frame. It offers a high spectral resolution in 230 spectral bands. With the provided software development kit, the number of analyzed spectral bands can be reduced to achieve a frame rate of up to 15000 fps with four bands.
- Wavelength ranges: 900 - 1700 nm (FX17)
- Spatial resolution: 640 pixels (FX17)
- Frame rates: full frame 670 Hz, 15000 Hz with fewer spectral bands (FX17)
- Signal-to-noise-ratio: 1000:1
- Interface: GigE or CameraLink
Applications
Vegetation analysis
Food inspection
Medicine
Plastics
Cosmetics
Downloads
Videos
Specim FX Series
