Supercontinuum Fiber Laser
Iceblink from FylaIceblink is a supercontinuum fiber laser covering the 450 – 2300 nm spectral range with over 3W of average power and superior stability (<0.5% std. dev.).
The spatial coherence and broad spectrum of the Iceblink makes it a great alterative to classic lamps, single-line lasers, LEDs, and ASE sources.
It is a very versatile white light source with a world of applications in the scientific and industrial sectors, including absorption/transmission measurements for material characterization, VIS, NIR and IR spectroscopy, single molecule spectroscopy and fluorescence excitation.
- SPECTRAL RANGE: 450-2300 nm
- AVERAGE POWER: >3000 mW
- Visible Range (450-750 nm) Average Power:~ 150 mW
- Pulse duration: < 10 ps (@ 1060 nm) / < 650 ps full spectrum
- Outstanding Power Stability
- VIS+NIR POWER BALANCE
Further information
Optical Spectrum
Specifications
Technical specifications
| Repetition Rate | 80 MHz |
| Power Stability | <0,5 % (std. dev.) |
| Polarization | Unpolarized |
| Output Port | Single Mode / 1.0 m (customizable) |
| Optical Output | Collimated (in the range 450-1000nm), Single-mode across full spectrum |
| Synchronization / Connections | TTL (SMA); NIM (SMA) Under request |
| Beam Diameter | @ 470nm ≤ 2mm / @ 580nm ≤ 2,5mm / @ 725nm ≤ 3,5mm / @ 1150nm ≤ 5,5mm |
| Spatial Mode | < 1.2 |
| Cooling | Thermoelectric cooler + air cooling |
| Power Requirements | 220 V / 110V - 50/60 Hz |
| Operating Temperature | 20 - 30 ºC |
| Storage Temperature | 0 - 60 ºC |
| Dimensions | 436x560x151 (WxDxH) |
Applications
- Microscopy (FRET, TIRF, CLSM…)
- Absorption / Transmission / Reflection Spectroscopy
- Lifetime Measurement
- Optical Device Characterization
- Metrology
- Hyperspectral Imaging
